Leather Patch Jig STL for xTool F1 Ultra, F2 Ultra & F2 Ultra UV

Description

Speed up your engraving workflow with this digital download STL file for the xTool F1 Ultra, F2 Ultra & F2 Ultra UV. Designed to hold four of the most common faux leatherette patch shapes: round (2.5 in), oval (3 in), square (2 in), and rectangle (3 in × 2 in), this printable jig delivers versatility and precision for every project. Perfect for creating custom hat patches, branding pieces, or decorative designs. No physical item will be shipped. Instant download available after purchase.

Designed for: xTool F1 Ultra, xTool F2 Ultra, xTool F2 Ultra UV
Does not fit: xTool F1, F1 Lite, or F2

Key Features

• Multi-shape fit for 2.5 in round, 3 in oval, 2 in square, and 3 in × 2 in rectangular leather patches
• Holds each patch securely for clean and repeatable engraving
• STL format ready for 3D printing in PLA, PETG, or other standard FDM materials
• Compatible with the xTool F1 Ultra, F2 Ultra & F2 Ultra UV using M4 × 0.7 mm screw positions
• Ideal for small business branding, team merchandise, and custom apparel accessories

What Is Included

• One STL file for the xTool F1 Ultra, F2 Ultra & F2 Ultra UV Leather Patch Jig
• Reference image showing recommended patch placement and orientation

Compatibility

• Machine: xTool F1 Ultra, xTool F2 Ultra, xTool F2 Ultra UV
• Material: Faux leatherette or leather patches in common 2.5 in to 3 in sizes
• Software: Any slicer compatible with STL import

Important Notes

• Digital product only. No physical jig or screws are supplied.
• Leather patches and accessories shown in images are for demonstration only.
• Manual framing is advised to ensure alignment accuracy across different machines.

Licence (please read): This STL file is for personal use only. Print the jig for your own workshop and sell anything you make with it. What is not allowed: selling or giving away the printed jig itself (original or modified), and sharing, reselling or redistributing this file or any modified version of it.

Printing Guidance

• Filament: PLA or PETG
• Layer height: 0.2 mm
• Infill: 25–35 percent
• Four or more perimeters for strength
• Test fit each patch size before engraving production batches

Usage Notes

• Mount the jig using the M4 × 0.7 mm screws from the xTool right-angle bracket
• Place the selected patch in the corresponding slot and ensure it sits flush
• Use the included XCS alignment file or manually frame before engraving

Optional FAQ

Q: Can this jig hold genuine leather patches
A: Yes. It is suitable for both faux and genuine leather, though thickness may vary slightly between brands.
